Easily adjust the peak draw weight and draw length of the Mathews 2024 to 2026 bows with the all-new SwitchWeight®X (SWX™) Mods. Programmed to deliver maximum efficiency at each draw weight and length, the SWX modules ensure peak performance tailored to every archer on the range or in the field.
*Sold as a set.
Switchweight X (SWX) Module sets for Mathews bows including ARC 30, ARC 34, Lift, Lift X, Lift RS and Lift XD. Designed to change both peak weight and draw length. (These do NOT fit the older Mathews bows from Phase 4 and earlier - for these, see the Switchweight Mods)
Module letter/draw length required depends on the model of bow you are fitting them to. Please refer to the chart below or call us to discuss if you're unsure what you need.
- Modules are available in peak weights of 55, 60, 65, 70, 75 and 80lb (not all variants are stocked - but special orders are welcome)
- Mods for the Lift RS with the Lightweight Limb give these lower weight ranges, 41, 45, 49, 52, 56, 60
- 85% let-off modules available, 80% by special order only.
| Mod | ARC 30 | ARC 34 | Lift/Lift X 29.5 | Lift/Lift X 33 | Lift RS (Standard Limb) | Lift XD |
| A | 30.5" | 32" | 30" | 31.5" | 29" | 33.5" |
| B | 30" | 31.5" | 29.5" | 31" | 28.5" | 33" |
| C | 30.5" | 32" | 29" | 30.5" | 28" | 32.5" |
| D | 30" | 31.5" | 28.5" | 30" | 27.5" | 32" |
| E | 30.5" | 32" | 28" | 29.5" | 27" | N/A |
| F | 30" | 31.5" | 27.5" | 29" | 26.5" | N/A |
| G | 30.5" | 32" | 27" | 28.5" | 26" | N/A |
| H | 30" | 31.5" | 26.5" | 28" | 25.5" | N/A |
| I | 30.5" | 32" | 26" | 27.5" | 25" | N/A |
| J | 30" | 31.5" | 25.5" | 27" | 24.5" | N/A |
| K | 30.5" | 32" | 25" | 26.5" | 24" | N/A |
| L | 30" | 31.5" | 24.5" | 26" | 23.5" | N/A |
